- 4-wire Cable
- 4-wire connector cable for FTX300 & FTX700 Bridge Amp
-
- ATEC302 TEC Temperature Controller
- •Bi-directional Temperature Control for Thermoelectric applications
•4 Temperature zone P, PI, PD, PID, Auto Tuning, Open-Loop Control
•High speed ADC, Wide range T/C, RTD, Thermistor Input Selectable
•DC Power Supply: 9~36V or 5V DC
•2 Programmable alarm Output
•RS232, RS485 and USB Communication with easy to use software GUI
•Complex program script for sophisticated temperature profile control
•IP-65 Splash proof front panel
-
- ATEC402 TEC Temperature Controller (DIN-Rail Embedded)
- •Bi-directional Temperature Control for Thermoelectric applications
•4 Temperature zone P, PI, PD, PID, Auto Tuning, Open-Loop Control
•High speed ADC, Wide range T/C, RTD, Thermistor Input Selectable
•DC Power Supply: 9~36V
•1 Programmable alarm Output
•Build in RS485 and USB port with easy to use software GUI
•Complex program script for sophisticated temperature profile control
•DIN-Rail mount, Pluggable terminals
-
- FTC100D TEC Temperature Controller
- •Bi-directional Temperature Control for Thermoelectric applications
•P, PI, PD, PID, Auto Tuning, Open-Loop Control
•T/C, RTD, Thermistor Input Selectable
•Universal Power Supply: 90~264V AC, 50/60 Hz
•2 Alarm Output
•RS232 Communication with easy to use software GUI
-
- F4 Process Controller
- •Saving space with the shortest length(55mm) behind panel.
•0.4" LED display showing SV/PV at a glance.
•Front panel protection with NEMA-4/IP65. (The attached packing is required.)
•Higher sampling (100ms) result in higher control performance.
•Protect the control object from thermal shock (rapid temperature change) with the excellent ramp rate facility.
•Protect the heating element from excess current during initial power-up.
•Thermistor sensor input (*Special Option)
•Free GUI PC control software (beta)
-
- FTX700D H-Bridge Amplifier for TEC Temperature Controller Systems
- •High efficiency bi-directional control for heating and cooling applications
•Solid-state bridge control
•High-power 700W FET H-bridge operation
•Designed for use with Accuthermo TE temperature controllers
•Ideal for high-power applications – 700W max power output
•Wide operating voltage 5~48V DC
-
- FTX300D H-Bridge Amplifier for TEC Temperature Controller Systems
- •FTX300D is an upgraded version of FTX300, all spec still the same
•High efficiency bi-directional control for heating and cooling applications
•Fully Integrated H-Bridge Driver
•Designed for use with Ferrotec FTC-series TE temperature controllers
•Ideal for Mid-range voltage applications – 180W max power output
-
- FTX100 H-Bridge Amplifier for TEC Temperature Controller Systems
- •High efficiency bi-directional control for heating and cooling applications
•Fully Integrated H-Bridge Driver
•Designed for use with Ferrotec FTC-series TE temperature controllers
•Ideal for Low-Voltage-Range Applications – 42W max power output
-
- THERMISTOR SPECIFICATIONS
- This specification defines ratings, dimension, insulation, climatic tests and mechanical characteristics for the 2.252 KΩ type thermistor.
